230V 18W Electronic Ballast for UV Lamps

230V 18W Electronic Ballast for UV Lamps
Pre-heat Start, Switching cycles up to 50000 times.

Overload Protection, Lamp Air Leakage Protection, Over Heat Protection,
Protection Against Moisture.

Isolation Class: Class 1
Isolation Voltage: 1.5KV AC / 5mA / 5s

One lamp operation. to be used for 2 wires or 4 wires uv germicidal lamps.

Compatible UV lamps: GPH150T5, GPH212T5,GPH217T5, GPH303T5, TUV11W, TUV16W

Product Details

Product Tags

230V 18W Electronic Ballast for UV Lamps

230V 18W Electronic Ballast for UV Lamps PH12-425-18

Product Parameters:

Operating Voltage Range
198-264
Max Input Power
21.5W
Max Input Current0.17A @ 230V
Lamp Power10-18W
Lamp Current0.35-0.42A
Operating Frequency50-70KHZ
Preheat Time
0.6-1.0 S
Preheat Current0.48-0.6A
Power Factor≥ 0.55
 Efficiency
 >80%
Total Harmonic Distortion<15%
Crest Factor
<1.7
Ambient Humidity
5%-85%
Ambient Temperature
-15-40℃
Max Case Temperature70℃
Case MaterialThermal Plastic
Safety NormEN61347-1-2-3, EN62493
 LVD NormLow voltage Directive 2014/35/EU
 EMC NormEN55015, EN55014, GB17743, GB17625, EN61000-3-2
 CertificatesCE & Rohs

Compatible Lamp Type:

This 230V input 18W Electronic ultraviolet ballast is compatible with low voltage uv bulbs: GPH150T5, GPH212T5,GPH217T5, GPH303T5, TUV11W, TUV16W. suitable for applications such as water treatment, air disinfection surface disinfections.


Dimension

Dimension for 18W Electronic Ballast for UV Lamps PH12-425-18

Size: 80*40*22mm  Carton Size: 460*280*140mm (100PCS load)

Wiring Diagram

Wiring diagram for uv ballast PH12-425-18

Cautions:

1.  Please make sure the power is off when you install or maintain the ballast

2. The distance between ballast and lamp tube should no longer than 5M.

3. The suggested wire specific: diameter 0.5-1mm, wire stripping 0.8-1mm
