230V Input 4-10W UV Light Ballast For Water Purification
230V Input 4-10W UV Light Ballast For Water Purification
Product Parameters:
| Operating Voltage Range | 198-264 |
| Max Input Power | 10W |
| Max Input Current | 0.08A @ 230V |
| Lamp Power | 4-10W |
| Lamp Current | 0.15-0.20A |
| Operating Frequency | 50-70KHZ |
| Preheat Time | 0.6-1.0 S |
| Preheat Current | 0.2-0.3A |
| Power Factor | ≥ 0.55 |
| Total Harmonic Distortion | <15% |
| Crest Factor | <1.7 |
| Ambient Humidity | 5%-85% |
| Ambient Temperature | -15-40℃ |
| Max Case Temperature | 70℃ |
| Case Material | Thermal Plastic |
Compatibale Lamp Types
This 4-10W UV light ballast is compatibale with following UV germicidal lamps, and widly used in drinking water purification, air disinfection, surface disinfection and so on.
PHILIPS: TUV4W/TUV6W/TUV8W/TUV10W
PLS-5W(4P)/PLS-7W(4P)/PLS-9W(4P)
LIGHT TECH: LTC4T5/LTC6T5/LTC8T5
ALTERNATIVES:
Advantages of the Electronic UV Ballast:
1> Energy efficient. cosuming 30% less electircity comparing to traditional magnetic ballasts.
2> Compact is zise, electronic ballast is smaller in size and lighter in weight.
3>Longer service life. less light output depreication longer service life. lower maintanence cost.
4> Stable operation and better control over light output.
5> Preheat start suitable for applications needs frequent start and stop. swithing cycles up to 50000 times
Dimension
Size: 80*40*22MM Carton Size:460*280*140 (100PCs Load)
Wiring Diagram
Suggested Cable Spec: Copper wire diamter 0.5-1.0mm
Cautions
1. Please make sure the power is off when you install or maintain the ballast
2. The distance between ballast and lamp tube should no longer than 5M.
