Fiverkoi Drum Filter for Pond 10T/H FR-DF-D80

Model: FR-DF-D80
Flow Rate: 10T/H (2640 Gallon)
Size: 800*600*720mm
Drum Size: 550mm(Diameter)*300mm(Height)
Housing Material: 304 Stainless Steel
Filtration Screen Material: 316 Stainless Steel
Screen Aperture: 100/75um
Inlet Size: DE50/DN40 -40mm
Outlet Size: DE75/DN65-65mm
Sewage Outlet: DE50/DN40-40mm
Suitable Water: 5-10m³
Feed Pump: Variable Frequency Pump: 80W
UV Lamps: 40W*2

Product Details

Product Tags

Fiverkoi 10T/H Drum Filter for Pond  FR-DF-D80

Fiverkoi 10T/H Drum Filter for Pond  FR-DF-D80.jpg


Product Parameters for 10T/H Rotary Drum Filter Koi

Product Parameters for 10T/H Rotary Drum Filter Koi.png


Product Features For Fiver's Pump Fed Drum Filter FR-DF-D80


Product Features For Fiver's Pump Fed Drum Filter FR-DF-D80.jpg


1> Long Life Span. Fiver's stainless steel drum filter with 1.5mm thick 304 chamber contructure and 316L filtration screen make the filter extremly strong, durable and corrosion resistance. with a life span up to 20 years.

2> Excellent Filtration Capability. This 10T/H rotary drum filter koi with a 100um diameter 550mm Length 300mm filtration drum. can effectively remove solid waste and debris from the water.

3> Fully Automatic Operation. with a atuomatic controller, the drum filter for pond can flush and sewage automaticly. carefree operation. no need to clean the filtration media offen as the traditonal filter system.

4> Flexibility. Compares to gravity feed drum filters, this pump fed drum filter are easier to install and operate pump can be conveniently connected to the filter and pond, eliminating the need for complex plumbing arrangements. This makes pump feed Combi Drum Filters a flexible practical and user-friendly option for pond owners, what's more it can also be used for existing ponds without settling pond.

5> Easy Installation and Less Space Required. this fish pond filter filter are easy to install requires less space for installation. can be used indoor and outdoor.

6> Comprehensive Solution for Maintaining Water Quality. This Combi Drum Filter for fish pond provides both mechanical and biological filtration in one unit. the filtration screen remove solid waste and debris from the water, uv lamps effectively killing harmful bacteria, algae, and other pathogens in the water while also promoting the biochemical filtration media helps the growth of beneficial bacteria that can break down harmful substances. can help reduce algae growth, improve water clarity, and enhance overall pond ecosystem balance.


Dimension for Pump Fed Drum Filter FR-DF-D80

pump fed drum filter FR-DF-D80.jpg


What Are the Advantages of Using a Combi Drum Filter in Fish pond Maintenance?

Using a Combi Drum Filter in fish pond maintenance offers several advantages. Firstly, the Combi Drum Filter provides both mechanical and biological filtration in one unit, making it a comprehensive solution for maintaining water quality. This helps to remove solid waste and debris from the water while also promoting the growth of beneficial bacteria that can break down harmful substances. The integrated design of the Combi Drum Filter simplifies the filtration process and ensures that the pond remains clean and healthy for fish and other aquatic life.

Additionally, Combi Drum Filters are known for their efficiency in removing debris and maintaining water clarity. The rotating drum with a fine mesh screen effectively captures particles and prevents clogging, reducing the need for frequent cleaning and maintenance. This can save time and effort for pond owners while ensuring consistent filtration performance.

Furthermore, the versatility of Combi Drum Filters allows for customization to suit the specific needs of different fish ponds. Pond owners can adjust the filtration settings, add additional filter media, or incorporate features like automatic backwashing to optimize water quality and create an ideal environment for fish to thrive.


Fiver Koi Pond Drum Filter Case Show
Fiver Koi Pond Drum Filter Case Show.jpg
