230V 2.1A 320W Preheat Start UV Disinfection Lamp Ballast

230V 2.1A 320W Preheat Start UV Disinfection Lamp Ballast

High Power Factor: >98%
Preheat start suitable for frequent starting.
Indicator function: with dry contact, which can be connected to remote control system to indicate the working status of the lamps.
5V DC output, connect to LED indicator output 5V DC when working normally, output 0V the lamp is failed

Can work with one lamp and two lamps.
Single Lamp: GPHHA1000T6, GPHHA1554T6, NN300/147XL, TUV325WXPT
Dual Lamps: GPHHA843T6, GPHHA357T6

INQUIRY

Product Details

Product Tags

230V 2.1A Instant Start 200W UV Lamp Power Supply for Amalgam UV Bulb

230V 2.1A Instant Start 200W UV Lamp Power Supply for Amalgam UV Bulb PH9-2100-320

Product Parameters for this 320W UV Disinfection Lamp Ballast

Start Mode	Preheat Start
Operating Voltage Range	198-264
Max Input Power	369W
Max Input Current	1.64A @ 230V
Lamp Power	320W Amalgam UV Lamp
Lamp Current	1.95-2.25A
Operating Frequency	40-70KHZ
Preheat Time	7-9 S
Preheat Current	2.5-3.1A
Power Factor	≥ 0.98
Efficiency	>90%
Total Harmonic Distortion	<15%
Crest Factor	<1.7
Ambient Humidity	5%-85%
Ambient Temperature	-15-40℃
Max Case Temperature	70℃
Case Material	Aluminum Shell
Safety Norm	EN61347-1-2-3, EN62493
LVD Norm	Low voltage Directive 2014/35/EU
EMC Norm	EN55015, EN55014, GB17743, GB17625, EN61000-3-2
Certificates	CE/UL/CCC

Product Features for UV Lamp Ballast Replacement

1> This 320W uv disinfection lamp ballast, is with high power factor. energy efficient.Less energy waste.

2> This uv light starter is with worldwide universal voltage, can work with 110V and 230V input.

3> This uv water sterilizer ballast with reliable quality, less than 0.3% repair rate,within warranty.

4> We offer OEM and ODM service for this uv-c lamp ballast .

Dimension for this UV Light Bulb Ballast

UV Light Bulb Ballast PH9-2100-320 320W Dimension

Size: 250*95*45mm Carton Size: 460*270*190mm(12PCS load)

Wiring Diagram for this UV Water Sterilizer Ballast

Wiring diagram A Single Lamp Operation: GPHHA1000T6, GPHHA1554T6, NN300/147XL, TUV325WXPT

Wiring Diagram B Dual Lamp Operation: GPHHA843T6, GPHHA357T6

Cautions:

1. Please make sure the power is off when you install or maintain the ballast

2. The distance between ballast and lamp tube should no longer than 5M.

3. The suggested wire specific: diameter 0.5-1mm, wire stripping 0.8-1mm

4. The aluminum shell should be grounded.

Why US for the amalgam uv lamp ballast?
