110V/230V Input Instant Start 155W UV Electronic Ballast
110V/230V Input Instant Start 155W UV Electronic Ballast
Product Parameters for UV Lamp Electronic Ballast
Operating Voltage Range | 99-264 |
Max Input Power | 165W |
Max Input Current | 0.73A @ 230V, 1.46 @ 110V |
Lamp Power | 155W UV Lamp |
Lamp Current | 0.75-0.85A |
Operating Frequency | 40-70KHZ |
Preheat Time | 7.0-9.0 S |
Preheat Current | 1.1-1.3A |
Power Factor | ≥ 0.98 |
Efficiency | >90% |
Total Harmonic Distortion | <15% |
Crest Factor | <1.7 |
Ambient Humidity | 5%-85% |
Ambient Temperature | -15-40℃ |
Max Case Temperature | 70℃ |
Case Material | Aluminum Shell |
Safety Norm | EN61347-1-2-3, EN62493 |
LVD Norm | Low voltage Directive 2014/35/EU |
EMC Norm | EN55015, EN55014, GB17743, GB17625, EN61000-3-2 |
Certificates | CE/UL/CCC |
Product Features for uv sterilizer ballast:
1> Reliable quality, less than 0.3% repair rate during past 5 years. no need to worry about customer complaint.
2> Competitive price, directly sell from uv ballast manufacturer save you cost.
3> CE, CCC, and UL Certified quality guaranty.
4> OEM and ODM services are available
5> 110/230 universal input voltage, can be used worldwide.
Dimension for this uv electronic ballast
Size: 250*65*40mm Carton Size: 460*270*190mm(18PCS Load)
UV Ballast Circuit Diagram
Loading Lamps: GPH1554T5HO, GHO64T5, TUV64T5HO, TUVPL-L95WHO, TL100
Cautions:
1. Please make sure the power is off when you install or maintain the ballast
2. The distance between ballast and lamp tube should no longer than 5M.
3. The suggested wire specific: diameter 0.5-1mm, wire stripping 0.8-1mm
4. The aluminum shell should be grounded.
